Multi-Point Scale and Offset Menu Configuration
18
INPUt value = Xin RS = Reading Scale RO = Reading Offset
Display Reading Value = Yrd IS = Input Scale IO = Input Offset
( . ) : Multiplication MS = Multi Scale MO = Multi Offset
DISPLAY READING VALUES
READING/INPUT SCALE & OFFSET MODE (y = ax + b)
MP.SC.OF IN.SC.OF Rd.SC.OF Yrd = (SCALE).Xin + (OFFSET)
disable disable enable RS.Xin + RO
disable enable disable IS.Xin + IO
enable disable disable MS.Xin + MO
disable enable enable RS.(IS.Xin + IO) + RO
enable enable disable IS.(MS.Xin + MO) + IO
enable disable enable RS.(MS.Xin + MO) + RO
enable enable enable RS.[IS.(MS.Xin + MO) + IO] + RO
Table 18-2. Reading / Input Scale & Offset Calculation Table
