Omega DP41-B User Manual

49
Input Type Selection
12
12.6 INPUT TYPE: (POTENTIOMETER)
ENTER INPUT TYPE MENU:
Press ‘MENU’ 1) Display shows "INPUt" Input Menu.
Press ‘RESET/ENTER’ 2)
Display flashes "VOLt" (default) or previous stored input type.
Press ‘䊱/MAX’ 3) Scroll through the available following input type selection list. Display:
"VOLt" (DC Voltage)
"CURRNt" (DC Current)
"bRIdGE" (Bridge)
"POt" (Potentiometer)
"tC" (Thermocouple)
"Rtd" (RTD)
If the displayed input type is "POt", press ‘RESET/ENTER’ to skip to
Step 6 ("POt" stops flashing).
POt “POt” POTENTIOMETER SUBMENU:
Press ‘䊱/MAX’ 4) Scroll through the available selection to "POt" (flashing).
Press ‘RESET/ENTER’ 5) Display shows "POt" again, but not flashing.
Press ‘RESET/ENTER’ 8) Display shows "StOREd" stored message momentarily and then
advances to the "RdG.CNF" Reading Configuration Menu.
To ensure the input range is properly polarized as desired for
configuration, the user must select "UN IPOL" input (default) or "bI POL"
bipolar accordingly in the input VOLt DC VOLTAGE SUBMENU with the
same voltage range before
selecting "BRIdGE" or "POt" Potentiometer
input type.
