Omega DP41-B User Manual

33
Specifications
108
33.1 CURRENT INPUT
INPUT RANGES (+10%): 0-20 mA and 4-20 mA
RESOLUTION: 1µA
MAXIMUM INPUT: 200 mA
INPUT OHMS: 5
33.2 VOLTAGE INPUT
INPUT RANGES:
UNIPOLAR: 100 mV 1 V 10 V 100 V
BIPOLAR: ±50 mV ±0.5 V ±5 V ±50 V
RESOLUTION: 1 µV 10 µV 100 µV 1 mV
MAX INPUT: 70 Vp 350 Vp 350 Vp 300 Vp
INPUT OHMS: 1G 1M 1M 1M
BIAS AMPS: 50 pA 5 pA 1 pA 1 pA
33.3 POTENTIOMETER INPUT
INPUT RANGES: 1 V or 10 V
RESOLUTION: programmed to 0.001%
33.4 THERMOCOUPLE INPUT
TC Type Degrees, Temperature : Accuracy
Celsius Fahrenheit Kelvin
J -210 to 760 : 0.2 -346 to 1400 : 0.3 +63.2 to 1673.2 :0.2
K -250 to 1250 : 0.2* -418 to 2282 : 0.3* +23 to 977.2 : 0.2*
E -270 to 1000 : 0.2 -454 to 1832 : 0.3 +3.2 to 1273.2 : 0.2
T -270 to 400 : 0.2 -454 to 752 : 0.3 +3.2 to 673.2 : 0.2
N -270 to 1300 : 0.2 -454 to 2372 : 0.3 +3.2 to 1573.2 : 0.2
R -50 to 1768 : 0.2 -58 to 3214 : 0.3 +223.2 to 2041.2 : 0.2
S -50 to 1768 : 0.2 -58 to 3214 : 0.3 +223.2 to 2041.2 : 0.2
B +100 to 1820 : 0.3 +212 to 3300 : 0.3 +373.2 to 2093.2 : 0.3
DINJ -200 to 900 : 0.6 -328 to 1652 : 1.0 +73.2 to 1173.2 : 0.6
* for K type: temperatures over 1250 deg C, accuracy will be 0.4C / 0.8F / 0.4K
For accurate full scale measurements below -40 degrees, you may need to
complete the full scale cold junction calibration procedure (Refer to
Section 16.3.1, Special Cold-Junction Calibration).
Calibration: NIST #135, DIN 43710
Reference Junction: Either a remote ice-point cell or an oven can be used in
place of the Cold-Junction Compensation Board. Curvalinear correction to
better than 40 dB ambient temperature rejection.
33.5 RTD INPUT RTD Type Temperature : Accuracy
Celsius Fahrenheit
Pt100/NIST -200 to 850 : 0.2 -328 to 1562 : 0.3
Pt100/DIN -200 to 900 : 0.2 -328 to 1652 : 0.3
Cu10(Linear) -200 to 200 : 1.0 -328 to 392 : 2.0
(Either of the two linearizations or the non-linearized scaling may be applied to RTDs
with R-zero values as low as 10 ohms or as high as 1000 ohms, using field
calibration and selection of excitation and input range.)
