12
Input Type Selection
46
12.3 INPUT TYPE: (DC VOLTAGE/PROCESS VALUE)
ENTER INPUT TYPE MENU:
Press ‘MENU’ 1) Display shows "INPUt" Input Menu.
Press ‘RESET/ENTER’ 2)
Display flashes "VOLt" (default) or previous stored input type.
Press ‘䊱/MAX’ 3) Scroll through the available following input type selection list. Display
flashes:
"VOLt" (DC Voltage)
"CURRNt" (DC Current)
"bRIdGE" (Bridge)
"POt" (Potentiometer)
"tC" (Thermocouple)
"Rtd" (RTD)
If the displayed input type is "VOLt", press ‘RESET/ENTER’ to skip to Step 6
("VOLt" stops flashing).
VOLt “VOLt” DC VOLTAGE SUBMENU:
Press ‘䊱/MAX’ 4) Scroll through the available selection to "VOLt" (flashing).
Press ‘RESET/ENTER’ 5) Display shows "VOLt" again, but not flashing.
Press ‘RESET/ENTER’ 6) Display flashes "UN IPOL" unipolar (default) or previously stored
selection of voltage input type "bI POL" bipolar.
You must choose bi-Polar or uni-Polar before selecting Bridge or
Potentiometer
Press ‘䊱/MAX’ 7) Scroll through the 2 available voltage input types to the selection of
your choice.
Press ‘RESET/ENTER’ 8) Display flashes "100 MV"(default) or previous stored input voltage
range selection. If the display matches your choice of Voltage range. Go
to Step 10.
Press ‘䊱/MAX’ 9) Scroll through the available voltage ranges to the selection of your
choice (see below Table for Voltage Input types/Ranges selection).
Press ‘RESET/ENTER’ 10)
Display shows "StOREd" stored message momentarily and then
advances to the "RdG.CNF" Reading Configuration Menu.
Display Voltage types Voltage Ranges
UN IPOL
100 MV
unipolar 100 milliVolt DC
1 V unipolar 1 Volt DC
10 V unipolar 10 Volt DC
100 V unipolar 100 Volt DC
bI POL
50 MV bipolar ± 50 milliVolt DC
500 MV bipolar ± 500 milliVolt DC
5 V bipolar ± 5 Volt DC
50 V bipolar ± 50 Volt DC
