Reading Configuration Menu
14
14.2 UNt.tMP Enter TEMPERATURE UNIT SELECTION SUBMENU:
1)
To enter TEMPERATURE UNIT SELECTION Submenu if display shows
"UNt.tMP" (Second Item of "RdG.CNF" Menu).
Press ‘RESET/ENTER’ 2) Display shows flashing "C" (default) and front display shows °C
accordingly at the bottom right side or previous temperature Unit
selection.
Press ‘䊱/MAX’ 3) Scroll through the 3 supported selections to the Temperature Unit of
your choice: "C", "F" and "k" (°C, °F and °K units).
Press ‘RESET/ENTER’ 4) Display advances to "dEC Pt" Decimal Point Setting Menu. If a change
was made, the controller will also show the "StOREd" stored message
momentarily.
14.3 dEC Pt Enter DECIMAL POINT CONFIGURATION SUBMENU:
Press ‘RESET/ENTER’ 5) Display shows "dP.ActV" Decimal Point Effect Selection menu.
Press ‘RESET/ENTER’ 6) Display flashes "yES" (default) as confirming that the decimal point
position is active otherwise "NO" as independent.
Press ‘䊱/MAX’ 7) To scroll or select the desired effect for your setting.
Press ‘RESET/ENTER’ 8) Display shows "StOREd" stored message momentarily then advances
to "Set dP" Decimal Point Setting menu.
Press ‘RESET/ENTER’ 9) Display shows "FFFFFF" (default) no decimal point option or previous
selection of decimal point location.
Press ‘䊱/MAX’ 10) Scroll through the 6 available selection as 000000, 00000.0, 0000.00,
000.000, 00.0000, and 0.00000 for the suitable choice to match your
selected input range and type.
Press ‘RESET/ENTER’ 11)
Display advances to "FILtER" Filter Configuration submenu. If a
change was made, the controller will also show "StOREd" stored
message momentarily.
For TC and RTD inputs. Only the following Decimal Point selections are available:
FFFFFF
FFFFF.F
FFFF.FF (least significant digit is an averaged display)
