1.3 Available Options and Accessories
The following options are available. Optional boards are either installed at the time of purchase, or
available as separate items and installed by the user after purchase.
-T/C Thermocouple Temperature Compensation Connector Kit
-4R Four Form-C SPDT Relay Output Board
-A Isolated 14 bit Analog Output Board
-C24 Serial Communications RS-232* + RS-485** + MODBUS
-EI Ethernet/Internet
-DC Low Voltage Power Option
Choose between Ethernet or Serial Communication option per meter. Serial
com mu ni ca tions come with one 6 ft. communications cable with phone plug
termination. Configuration Software and latest Operational Manual are
available at the website listed in this manual.
* Recommend purchase of 9SC2 or 25SC2 (see OPTIONS below)
** Recommend purchase of 9SC4 or 25SC4 (see OPTIONS below)
MODEL
NUMBER DESCRIPTION
FS Custom Calibration/configuration
BL Blank lens
9SC2 9-pin Serial Connector for RS-232
9SC4 9-pin Serial Connector for RS-485
25SC2 25-pin Serial Connector for RS-232
25SC4 25-pin Serial Connector for RS-485
RP18 19” Rack panel for one (1) meter
RP28 19” Rack panel for two (2) meters
RP38 19” Rack panel for three (3) meters
SPC4 1/8 DIN NEMA 4 heavy duty cover with thumb screws
SPC18 1/8 DIN NEMA 4 Splash Proof lens cover
TP1 Trimplate adapter
1
Introduction
2
