Specifications
33
1. Test with Analog Out (AN03)
Sample Rate Process (100 mV) TC (K type)
Rate (ms) Rate (ms)
0 7(135) 7(135)
1 14(68) 14(68)
2 27(36) 27(36)
3 52(19) 41(24)
4 100(10) 41(24)
5 142(7) 41(24)
2. Test with Communication (Baud Rate at 19200 bps, Continuous Mode)
Sample Rate Process (100mV) TC (K type)
Rate (ms) Rate (ms)
0 7(135) 7(135)
1 14(68) 14(68)
2 27(36) 27(36)
3 52(19) 33(30)
4 71(14) 33(30)
5 71(14) 33(30)
3. Test with Command Mode (Baud Rate at 19200 bps, Command Mode)
Sample Rate Process (100mV) Rate (ms) TC(K type) Rate (ms)
(Turn Around - Time ms) (Turn Around - Time ms)
0 7(135 ms) 7(135 ms)
1 14(68 ms) 14(68 ms)
2 27(36 ms) 28(36 ms)
3 52(19 ms) 28(30 ms)
4 60(14 ms) 28(30 ms)
5 60(14 ms) 28(30 ms)
Table 33-1 Reading Rate
For the Command Mode, if the command-sending turn-around time is shorter than the
turn-around time in the above table (Refer to Process or TC), the response will have some
duplicate readings. For example, if the sample rate is 1 in process, the command-sending
turn-around time should be larger than 68 ms.
