34
Factory Preset Values
116
JUMPER CONFIGURATIONS--
S1 = K
S2 = A, B
S3 = A, C
S4 = NONE
NOTE: extra jumpers are located in
storage positions.
Sensor Excitation = 10Vdc
INPUT SELECTION : INPUt
VOLTAGE: VOLt
Voltage type = UNIPOL
Range = 100MV
If choose bI POL
Range = 50MV
If choose different INPUt--
If tC: Type = J tC
If Rtd: Type = 2Pt.392
If CURRNt: Range = 0-20MA
READING CONFIG : RdG.CNF
Rd.SC.OF = dISAbL
If choose ENAbLE = dIRECt
UNt.tMP = C
dEC.Pt
dP.ACtV=yES
SEtdP=FFFFFF
FILtER
CNtby=001
FILt.tP=A.b.C.FIL
FILt.tM=016
FLS.dSP
SP1.FLS=dISAbL
SP2.FLS= dISAbL
AL1.FLS= dISAbL
AL2.FLS= dISAbL
bRIGHt=H.bRt
INPUT CONFIGURATION : INP.CNF
LIN.FRE=60
Ad.RAtE=0
MOdE
If Choose tC:
tC.CO.JC=ENAbLE
C.JUN.OF-dISAbL
If Choose bRIdGE:
bRDG.LM=NORMAL
RAtIO=dISAbL
IN.SC.OF=dISAbL
OUTPUT CONFIGURATION : OUt.CNF
ANA.OUt = dISAbL
If Choose ENAbLE:
MOdE = VOLt
OUt.tYP= UNFILt
SETPOINT CONFIG: SP.CNF
SP CNF=dISAbL
If choose ENAbLE
SP1.CNF:
ACtIVE=AbOVE
N.StAtTE=N.OPEN
SP2.CNF:
ACtIVE=bELOU
N.StAtE=N.OPEN
SPdb=0200
