Output Configuration Menu
72
MOdE Enter OUTPUT MODE CONFIGURATION SUBMENU:
Press ‘RESET/ENTER’ 5) Display shows "StOREd" stored message momentarily and advances
to "MOdE" to allow users to select Output type as Voltage (0-10Vdc or
Current (4-20mA-dc) source.
Press ‘RESET/ENTER’ 6) Display flashes "VOLt" (default) DC-Voltage output option or previous
selection ("CURRNt" DC-Current output).
OUt.tyP Enter OUTPUT TYPE CONFIGURATION SUBMENU:
Press ‘RESET/ENTER’ 7) Display shows "OUt.tyP" Output Type Submenu.
Press ‘RESET/ENTER’ 8) Display flashes "UNF ILt" Unfiltered option or previous selection.
Press ‘䊱/MAX’ 9) Scroll though and select the following options for your choice of setting:
"UNF ILt" :Transmits the unfiltered value of your signal input.
"FILtRd" : Transmits the filtered value of your signal input.
"PEAk" : Transmits the recorded Peak "HI RdG" Reading value(s).
or
"VALLy" : Transmits the recorded Valley "LO RdG" Reading value(s).
FILtRd
(Filtered)
OUt.tyP
(Output Type)
UNFILt
(Unfiltered)
PEAk
VALLy
