Omron CP1L - DIN Track Installation

108
Mounting Section 3-3
2. Insert the Expansion I/O Unit's connecting cable into the CPU Unit's or the
Expansion I/O Unit's expansion connector.
3. Replace the cover on the CPU Unit's or the Expansion I/O Unit's expansion
connector.
3-3-3 DIN Track Installation
1,2,3... 1. Use a screwdriver to pull down the DIN Track mounting pins from the back
of the Units, and mount the Units to the DIN Track.
