152
1:1 Link Area Section 4-3
■ I/O Word Allocations to Expansion Units
CPU Unit with 40 I/O Points + TS002 + DA041 + 40ED
4-3 1:1 Link Area
The 1:1 Link Area contains 1,024 bits (64 words) with addresses ranging from
CIO 3000.00 to CIO 3063.15 (CIO 3000 to CIO 3063).
These bits are used to create 1:1 links (i.e., shared data link areas) by con-
necting the RS-232C ports of two PLCs, including the CP1L, CPM1A,
CPM2A, CPM2B, CPM2C, SRM1(-V2), CQM1H, and C200HX/HG/HE(-Z).
Refer to
6-3-6 1:1 Links
for information on using 1:1 links.
DA041
TS002
Bit 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
CIO 0
CIO 1
CIO 2
CIO 3
CIO 4
CIO 5
CIO 6
CIO 7
CIO 100
CIO 101
CIO 102
CIO 103
CIO 104
CIO 105
CIO 106
CIO 107
Do not use.
Can be used as work bits.
Can be used as work bits.
Do not use.
CIO 0.00 to CIO 0.11
CIO 1.00 to CIO 1.11
CIO 100.00 to CIO 100.07
CIO 101.00 to CIO 101.07
CPU Unit
(40 I/O points)
CIO 2 to CIO 5
No outputs
No inputs
CIO 2 to CIO 6.11
CIO 7 to CIO 7.11
2
4
in
p
u
t p
o
in
ts
16 output points
2
4
in
p
u
t p
o
in
ts
16 output points
CIO 102 to CIO 105
CIO 106.00 to CIO 106.07
CIO 107.00 to CIO 107.07
CPU Unit with 40 I/O points
First Unit: Temperature Sensor Unit
Third Unit: Expansion I/O Unit with 40
CPU Unit with 40 I/O points
Second Unit: Analog Output Unit
Third Unit: Expansion I/O Unit with 40 I/O points
First Unit:
Temperature Sensor Unit
Second Unit:
Analog Input Unit
Third Unit:
Expansion I/O Unit with 40 I/O points
Input bits
Input bits
Output bits
Output bits
RS-232C
CIO 3000
CIO 3031
CIO 3032
CIO 3063
Master
Slave
1:1 Links
CIO 3000
CIO 3031
CIO 3032
CIO 3063
Write words
Write words
Read words
Read words
CP1L,
CPM1A,
CPM2A,
CPM2B,
CPM2C,
SRM1(-V2),
CQM1H,
C200HX/HG/HE(-Z),
Other C-series PLC
