Omron CP1L User Manual

589
Appendix B
Dimensions Diagrams
CP1L CPU Units
CPU Units with 10 I/O Points
CPU Units with 14 or 20 I/O Points
CPU Units with 30 I/O Points
66
56
110 100
90
Two, 4.5 dia.
85
8
90100110
76
86
8
85
Four, 4.5 dia.
90100110
120
130
8
85
Four, 4.5 dia.

Omron CP1L Specifications

General

Model	CP1L
Data Memory Capacity	32K words
Program Capacity	10K steps
Communication Ports	USB, RS-232C
Expansion	I/O
Pulse Output	100 kHz
Built-in I/O	Digital I/O
Expansion Slots	Supports up to 3 expansion units
Operating Voltage	100-240 VAC or 24 VDC (varies by model)
Operating Temperature	55 degrees Celsius
Storage Temperature	75 degrees Celsius
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude
Shock Resistance	147 m/s^2, 3 times in X, Y, and Z directions
