Computing the Cycle Time Section 2-7
2-7-4 I/O Refresh Times for PLC Units
CP-series Expansion Unit and Expansion I/O Unit I/O Refresh Times
Note The I/O refresh time for CPU Unit built-in I/O is included in overhead process-
ing.
2-7-5 Cycle Time Calculation Example
The following example shows the method used to calculate the cycle time
when CP-series Expansion I/O Units only are connected to a CP1L CPU Unit.
Name Model I/O refresh time per Unit
Expansion I/O Units CP1W-40EDR
CPM1A-40EDR
0.39 ms
CP1W-40EDT
CPM1A-40EDT
0.39 ms
CP1W-40EDT1
CPM1A-40EDT1
0.39 ms
CP1W-32ER 0.33 ms
CP1W-32ET
CP1W-32ET1
0.33 ms
CP1W-20EDT
CPM1A-20EDT
0.18 ms
CP1W-20EDT1
CPM1A-20EDT1
0.18 ms
CP1W-16ER
CPM1A-16ER
0.25 ms
CP1W-16ET
CP1W-16ET1
0.25 ms
CP1W-8ED
CPM1A-8ED
0.13 ms
CP1W-8ER
CPM1A-8ER
0.08 ms
CP1W-8ET
CPM1A-8ET
0.08 ms
CP1W-8ET1
CPM1A-8ET1
0.08 ms
Analog Input Units CP1W-AD041
CPM1A-AD041
0.61 ms
Analog Output Units CP1W-DA041
CPM1A-DA041
0.33 ms
Analog I/O Units CPM1A-MAD01 0.29 ms
CP1W-MAD11
CPM1A-MAD11
0.32 ms
Temperature Sensor Units CP1W-TS001
CPM1A-TS001
0.25 ms
CP1W-TS002
CPM1A-TS002
0.52 ms
CP1W-TS101
CPM1A-TS101
0.25 ms
CP1W-TS102
CPM1A-TS102
0.52 ms
DeviceNet I/O Link Unit CPM1A-DRT21 0.38 ms
CompoBus/S I/O Link Unit CP1W-SRT21
CPM1A-SRT21
0.21 ms
