Omron CP1L User Manual

118
Wiring CPU Unit I/O Section 3-5
3-5 Wiring CPU Unit I/O
3-5-1 I/O Wiring for CPU Units with 60 I/O Points
Input Wiring (Upper Terminal Block)
The input circuits have 36 points/common. Use power lines with sufficient cur-
rent capacity for the COM terminals.
Output Wiring (Lower Terminal Block)
Relay Outputs
(CP1L-M60D
R-A and
CP1L-M60DR-D)
AC-power-supply models have a 24-VDC output terminals (+/−) on the lower
terminal block. They can be used as a DC power supply for the input circuit.
L1 L2/N COM 01 03 05 07 09 01 03 05 07 09
00 02 04 06 08 00 02 04 06 08
24 VDC
+
-
-
+
CIO 0
CIO 1
CIO 0
CIO 1
03 05 07 09
00 02 04 06 08
CIO 2
CIO 2
01
10
11 11
10
11
10
CIO 100
CIO 101
CIO 100
CIO 101
L L L L L L L LLLL
L
LLLLL
L L
CIO 102
CIO 102
+ 00 01 02 04 05 07 00 02 04 05 07 00 02 04 05 07
- COM COM COM 03 COM 06 COM 01 03 COM 06 COM 01 03 COM 06
L
L L L
L

Omron CP1L Specifications

General

Model	CP1L
Data Memory Capacity	32K words
Program Capacity	10K steps
Communication Ports	USB, RS-232C
Expansion	I/O
Pulse Output	100 kHz
Built-in I/O	Digital I/O
Expansion Slots	Supports up to 3 expansion units
Operating Voltage	100-240 VAC or 24 VDC (varies by model)
Operating Temperature	55 degrees Celsius
Storage Temperature	75 degrees Celsius
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude
Shock Resistance	147 m/s^2, 3 times in X, Y, and Z directions
