Trouble Shooting Section 8-7
8-7-3 Deleting EEPROM Error
1,2,3...
1. A flashing error screen will be displayed when an error occurs.
The following table shows the display items.
According to the error message, the setting of User Monitor Screen 2, line
4 is corrupted.
2. Press the ESC button to exit the screen. Once the EEPROM Error Screen
has disappeared, the display will return to normal.
3. Enter the User Monitor Setup Screen 2, line 4.
User settings backed up in EEPROM are replaced by default settings.
Then reset the screen.
a
c
b
No. Description
a Error type
User Monitor setting error
Message setting error
Timer Switch setting error
Language setting error
Backlight setting error
Contrast setting error
b Screen No.
cLine No.
To Next Page
