Specifications Section 8-2
8-2 Specifications
Item Specification
Model CP1W-DAM01
Type Built-in
Serial port Only port 1
Communication protocol Toolbus
DC consumption
5V : 40mA
24V : 0mA
Dimensions 43×36×23 mm (W×H×D)
Weight 20g max.
Screen size 2.6cm×1.45cm
Total characters on screen 4 lines×12 characters
Font size 5×7 dot
Backlight color Green / Red
Display language English / Japanese (Katakana)
Ambient operating temperature 0 to 55°C
Ambient operating humidity 10% to 90% (with no condensation)
Atmosphere No corrosive gas.
Ambient storage condition (with no condensation)
Humidity[%]
Temperature[˚C]
100
90
80
70
60
807060
50
40
(65 , 90%)
(70 , 60%)
(75 , 40%)
