LCD Option Board Function Section 8-6
8-6-18 LCD Factory Setting
This function can initialize the factory setting of the LCD Option Board. The
operation method will be shown in the following example.
1,2,3...
1. Switch to the Setup Mode.
2. Press the Down button to select
Other .
3. Press the OK button to enter the Other menu.
4. Press the Down button to select
FactorySet .
5. Press the OK button to enter the Factory Setting Screen.
6. Press the Down button to select OK.
Note Selecting
Cancel will result in a return to the previous menu.
7. Press the OK button to start initializing.
8. When the initializing is finished, it will display a complete screen.
9. Press the ESC or OK button to restart the LCD Option Board.
