126
Wiring CPU Unit I/O Section 3-5
Output Wiring (Lower Terminal Block)
Relay Outputs
(CP1L-L10DR-A and
CP1L-L10DR-D)
AC-power-supply models have a 24-VDC output terminals (+/−) on the lower
terminal block. They can be used as a DC power supply for the input circuit.
Sinking Transistor
Outputs (CP1L-L10DT-A
and CP1L-L10DT-D)
AC-power-supply models have a 24-VDC output terminals (+/−) on the lower
terminal block. They can be used as a DC power supply for the input circuit.
Sourcing Transistor
Outputs (CP1L-L10DT1-D)
CIO 100
L L L
L
+
00 01 02
- COM COM COM 03
CIO 100
CIO 100
L L L
L
00 02
COM COM COM 03
CIO 100
+
-
01
CIO 100
L L L
L
NC 00 01 02 NC
NC COM COM COM 03 NC
CIO 100
