Pulse Outputs Section 5-2
Single-phase Pulse Output with Acceleration/Deceleration
■ PULS(886) and ACC(888)
Determine the pulse output method,
output frequency, and port.
Wire the outputs.
PLC Setup settings
• Enable/disable the origin search function. Set the
various origin search parameters if the origin
search function is enabled.
Ladder program
• PULS(886): Specify port number and set the number
of output pulses.
• ACC(888): Specify port number and set the output
method (CW/CCW method or Pulse + direction
method) and pulse output control with
acceleration/deceleration (the same rate is used for
both acceleration and deceleration.)
• INI(880): Specify port number and stop pulse output
when necessary.
• PRV(881): Specify port number and read pulse
output PV when necessary.
• Pulse output method
• CW/CCW inputs
• Pulse + direction inputs
• Output frequency: 1 Hz to 100 kHz (1 Hz units)
J models: 1Hz to 20 kHz (1 Hz units)
