Pulse Outputs Section 5-2
<0.08>
b88
<0.09>
b90
000022
(000084)
Limit Input Setting
0.04
Built-in
input
A540.08 CW limit input
signal X axis
000023
(000086)
0.05
Built-in
input
A540.09 CCW limit input
signal X axis
000024
(000088)
0.08
Built-in
input
A541.08 CW limit input
signal Y axis
000025
(000090)
0.09
Built-in
input
A541.09
CCW limit input
signal Y axis
