⚫ 3-phase 400-V class
Model
Normal/
Light load
mode
Maximum
applicable
motor
capacity
[kW]
Rated
input
current
[A]
Power cable,
ground cable
[mm
2
]
*1*2*3
Terminal
screw
size
Tightening
torque
[N·m]
*2
Molded
case
circuit
breaker
(MCCB)
*2
3G3MX2-A4004-EV2
Heavy load
0.4
1.8
AWG16 (1.25)
M4
1.4
5 A
Light load
0.75
2.1
AWG16 (1.25)
5 A
3G3MX2-A4007-EV2
Heavy load
0.75
3.6
AWG16 (1.25)
M4
1.4
5 A
Light load
1.5
4.3
AWG16 (1.25)
10 A
3G3MX2-A4015-EV2
Heavy load
1.5
5.2
AWG16 (1.25)
M4
1.4
10 A
Light load
2.2
5.9
AWG16 (1.25)
10 A
3G3MX2-A4022-EV2
Heavy load
2.2
6.5
AWG14 (2.0)
M4
1.4
10 A
Light load
3.0
8.1
AWG14 (2.0)
15 A
3G3MX2-A4030-EV2
Heavy load
3.0
7.7
AWG14 (2.0)
M4
1.4
15 A
Light load
4.0
9.4
AWG14 (2.0)
15 A
3G3MX2-A4040-EV2
Heavy load
4.0
11.0
AWG12 (3.5)
M4
1.4
20 A
Light load
5.5
13.3
AWG12 (3.5)
20 A
3G3MX2-A4055-EV2
Heavy load
5.5
16.9
AWG12 (3.5)
M5
3.0
30 A
Light load
7.5
20.0
AWG10 (5.5)
30 A
3G3MX2-A4075-EV2
Heavy load
7.5
18.8
AWG10 (5.5)
M5
3.0
30 A
Light load
11
24.0
AWG10 (5.5)
50 A
3G3MX2-A4110-EV2
Heavy load
11
29.4
AWG10 (5.5)
M6
3.9 to 5.1
50 A
Light load
15
38.0
AWG6 (14)
60 A
3G3MX2-A4150-EV2
Heavy load
15
35.9
AWG6 (14)
M6
3.9 to 5.1
60 A
Light load
18.5
44.0
AWG6 (14)
75 A
*1. The wire size is based on H-IV wire (with a heat resistance of 75°C).
*2. For compliance with the UL standard requirements, be sure to perform wiring according to A-4 UL/cUL Stan-
dards Cautions on page A-9.
*3. The cable is applicable to wiring to the R/L1, S/L2, T/L3, U/T1, V/T2, W/T3, +1, P/+, RB, N/-, and G ( ) terminals.
⚫ Single-phase 200-V Class
Model
Normal/
Light load
mode
Maximum
applicable
motor
capacity
[kW]
Rated
input
current
[A]
Power cable,
ground cable
[mm
2
]
*1*2*3
Terminal
screw
size
Tightening
torque
[N·m]
*2
Molded
case
circuit
breaker
(MCCB)
*2
3G3MX2-AB001-EV2
Heavy load
0.1
1.3
AWG16 (1.25)
M3.5
1.0
5 A
Light load
0.2
2.0
AWG16 (1.25)
5 A
3G3MX2-AB002-EV2
Heavy load
0.2
3.0
AWG16 (1.25)
M3.5
1.0
5 A
Light load
0.4
3.6
AWG16 (1.25)
5 A
3G3MX2-AB004-EV2
Heavy load
0.4
6.3
AWG16 (1.25)
M3.5
1.0
10 A
Light load
0.55
7.3
AWG16 (1.25)
15 A
3G3MX2-AB007-EV2
Heavy load
0.75
11.5
AWG12 (3.5)
M4
1.4
15 A
Light load
1.1
13.8
AWG12 (3.5)
20 A
3G3MX2-AB015-EV2
Heavy load
1.5
16.8
AWG10 (5.5)
M4
1.4
20 A
Light load
2.2
20.2
AWG10 (5.5)
30 A
3G3MX2-AB022-EV2
Heavy load
2.2
22.0
AWG10 (5.5)
M4
1.4
30 A
Light load
3.0
24.0
AWG10 (5.5)
50 A
*1. The wire size is based on H-IV wire (with a heat resistance of 75°C).
*2. For compliance with the UL standard requirements, be sure to perform wiring according to A-4 UL/cUL Stan-
dards Cautions on page A-9.
*3. The cable is applicable to wiring to the L1, N, U/T1, V/T2, W/T3, +1, P/+, RB, N/-, and G ( ) terminals.
