3 Operation and Test Run
3 - 22
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Open the Status folder in the project and double-click the status information.
The window corresponding to the selected status information opens.
Display
Description
[Digital Inputs]
Displays the current ON/OFF status information and function set to
each input terminal.
[Digital Outputs]
Displays the current ON/OFF status information and function set to
each output terminal.
[Monitor Mode]
Displays the internal status values of the inverter. These status values
are similar to those displayed in the monitor mode (dxxx) of the inverter.
[Alarms]
Displays an alarm history of the current and past alarms.
Status Function of CX-Drive
