Omron MX2 Series User Manual

4 Parameter List
4 - 12
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter
No.
Function name
Monitor or data range
Default
data
Set
data
Changes
during
RUN
Unit
Page
Frequency
adjustment
A101
OI Start Frequency
0.00 to 590.00
0.00
Enabled
Hz
P. 7-25
A102
OI End Frequency
0.00
Enabled
A103
OI Start Ratio
0. to OI End Ratio
20.
Enabled
%
A104
OI End Ratio
OI Start Ratio to 100
100.
Enabled
%
A105
OI Start Selection
00: OI Start Frequency (A101)
01: 0 Hz
00
Enabled
−
Acceleration/Deceleration
A131
Acceleration Curve
Parameter
1 (Small curve) to 10 (Large curve)
2
Enabled
−
P. 5-33
A132
Deceleration Curve
Parameter
2
Enabled
Calculation
frequency
A141
Calculation Fre-
quency Selection 1
00: Digital Operator (A020/A220)
01: Digital Operator (Volume)
*1
02: Input O (Voltage)
03: Input OI (Current)
04: Modbus communication
05: Option
07: Pulse train frequency
02
Enabled
−
P. 7-39
A142
Calculation Fre-
quency Selection 2
03
Enabled
A143
Calculation Function
Operator Selection
00: Addition (A141 + A142)
01: Subtract ion (A141 − A142)
02: Multiplication (A141  A142)
00
Enabled
−
A145
Frequency Addition
Amount Setting
0.00 to 590.00
0.00
Enabled
Hz
P. 7-39
A146
Frequency Addition
Sign Selection
00: Frequency reference + A145
01: Frequency reference − A145
00
Enabled
−
Acceleration/Deceleration
A150
EL-S Shape Acceler-
ation Curve Ratio 1
0. to 50.
10.
Disabled
%
P. 5-33
A151
EL-S Shape Acceler-
ation Curve Ratio 2
10.
Disabled
A152
EL-S Shape Deceler-
ation Curve Ratio 1
10.
Disabled
A153
EL-S Shape Deceler-
ation Curve Ratio 2
10.
Disabled
Deceleration
stop
A154
Deceleration Stop
Frequency
0.00 to Starting Frequency: Disabled
Frequency above Starting Frequency to
590.00
0.00
Enabled
Hz
P. 7-37
A155
Deceleration Stop
Time
0.0: Disabled
0.1 to 60.0
0.0
Enabled
s
PID
A156
PID Sleep Operation
Level
0.00 to 590.00
0.00
Enabled
Hz
P. 7-44
A157
PID Sleep Operation
Delay Time
0.0 to 25.5
0.0
Enabled
s
*1. This setting is enabled when the Digital Operator with the volume control (Model: 3G3AX-OP01) is connected.

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
