4 Parameter List
4 - 31
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter
No.
Function name
Monitor or data range
Default
data
Set
data
Changes
during
RUN
Unit
Page
I/O terminal
function
C146
Logic Output Signal 2
Selection 2
Same as options for C021 (33 to 35:
LOG1 to LOG3, 63: OPO, and 255: no
cannot be selected.)
00
Enabled
−
P. 7-85
C147
Logic Output Signal 2
Operator Selection
00: AND
01: OR
02: XOR
00
Enabled
−
C148
Logic Output Signal 3
Selection 1
Same as options for C021 (33 to 35:
LOG1 to LOG3, 63: OPO, and 255: no
cannot be selected.)
00
Enabled
−
C149
Logic Output Signal 3
Selection 2
Same as options for C021 (33 to 35:
LOG1 to LOG3, 63: OPO, and 255: no
cannot be selected.)
00
Enabled
−
C150
Logic Output Signal 3
Operator Selection
00: AND
01: OR
02: XOR
00
Enabled
−
C160
Multi-function Input
1 Response Time
0. to 200. ( 2 ms)
1.
Enabled
ms
P. 5-47
C161
Multi-function Input
2 Response Time
1.
Enabled
C162
Multi-function Input
3 Response Time
1.
Enabled
C163
Multi-function Input
4 Response Time
1.
Enabled
C164
Multi-function Input
5 Response Time
1.
Enabled
C165
Multi-function Input
6 Response Time
1.
Enabled
C166
Multi-function Input
7 Response Time
1.
Enabled
C169
Multi-step Speed/
Position Determina-
tion Time
0. to 200. ( 10 ms)
0.
Enabled
ms
P. 6-45
4
4-3 Extended Function Mode
