Omron MX2 Series User Manual

5 Basic Settings
5 - 13
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Para-
meter
No.
Function
name
Setting range
Default data
Initialization at
load mode
switching
Heavy load (CT)
Light load (VT)
Heavy
load (CT)
Light
load (VT)
Normal
to Light
Light to
Normal
C030
Digital Current
Monitor Refer-
ence Value
0.20  Heavy load rated
current to 2.00 
Heavy load rated current [A]
0.20  Light load rated
current to 2.00  Light load
rated current [A]
Normal-
load rated
current [A]
Light load
rated
current [A]
Conversion
*1
Conversion
*1
C039
Low Current
Detection Level
0.00 to 2.00  Heavy load
rated current [A]
0.00 to 2.00  Light load
rated current [A]
Normal-
load rated
current [A]
Light load
rated
current [A]
Conversion
*1
Conversion
*1
C041
1st Overload
Warning Level
0.00: Overload warning
detection disabled
0.01 to 2.00  Heavy load
rated current [A]
0.00: Overload warning
detection disabled
0.01 to 2.00  Light load
rated current [A]
1.15 
Normal-
load rated
current [A]
1.15 
Light load
rated
current [A]
Conversion
*1
Conversion
*1
C241
2nd Overload
Warning Level
C111
1st Overload
Warning Level 2
0.00: Overload warning
detection disabled
0.01 to 2.00  Heavy load
rated current [A]
0.00: Overload warning
detection disabled
0.01 to 2.00  Light load
rated current [A]
1.15 
Normal-
load rated
current [A]
1.15 
Light load
rated
current [A]
Conversion
*1
Conversion
*1
H003
1st Motor
Capacity
0.1 to 18.5 [kW]
Setting in steps
*2
Same as the setting range for
heavy load mode
Max.
applicable
motor
capacity for
heavy load
[kW]
Max.
applicable
motor
capacity for
light load
[kW]
Disabled
Disabled
H203
2nd Motor
Capacity
*1. Conversion: The set current value will be converted at the ratio of the rated current for the heavy load/light load mode.
(Example) If you change from a light load mode setting of 5 A (rated current: 10 A) to the heavy load mode (rated current:
8 A), the current value will be converted as follows: Rated current 8 A × 50% (5 A/10 A) = 4 A.
*2. Setting in steps: Steps of 0.1/0.2/0.4/0.55/0.75/1.1/1.5/2.2/3.0/3.7/4.0/5.5/7.5/11.0/15.0/18.5 [kW] can be selected.
In the light load mode, the following parameters are not displayed.
Parameter No.
Function name
Parameter No.
Function name
d009
Torque Reference Monitor
H005/H205
1st/2nd Speed Response
d010
Torque Bias Monitor
H020/H220
1st/2nd Motor Parameter R1
d012
Output Torque Monitor
H021/H221
1st/2nd Motor Parameter R2
b040
Torque Limit Selection
H022/H222
1st/2nd Motor Parameter L
b041
Torque Limit 1
(Four-quadrant Mode Forward
Power Running)
H023/H223
1st/2nd Motor Parameter Io
b042
Torque Limit 2
(Four-quadrant Mode Reverse
Regeneration)
H024/H224
1st/2nd Motor Parameter J
b043
Torque Limit 3
(Four-quadrant Mode Reverse
Power Running)
H030/H230
1st/2nd Motor Parameter R1
(Auto-tuning Data)
b044
Torque Limit 4
(Four-quadrant Mode Forward
Regeneration)
H031/H231
1st/2nd Motor Parameter R2
(Auto-tuning Data)
b045
Torque LADSTOP Selection
H032/H232
1st/2nd Motor Parameter L
(Auto-tuning Data)
b046
Reverse Rotation Prevention Selec-
tion
H033/H233
1st/2nd Motor Parameter Io
(Auto-tuning Data)
C054
Overtorque/Undertorque Selection
H034/H234
1st/2nd Motor Parameter J
(Auto-tuning Data)
C055
Overtorque/Undertorque Level
(Forward Power Running)
P033
Torque Reference Input Selection
C056
Overtorque/Undertorque Level
(Reverse Regeneration)
P034
Torque Reference Setting
5
5-2 V/f Control Settings
5-2-2 Heavy load/Light Load Selection

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
