Omron MX2 Series User Manual

8 Communications Functions
8 - 42
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Register
No.
Modbus register
spec. No
Function name
Parameter No.
R/W
Monitor or setting
data
Data
resolution
0006 hex
0005 hex
PID Feedback
*1
−
R/W
0 to 10000
0.01 [%]
0007 to
0010 hex
−
Reserved
−
−
−
−
0011 hex
0010 hex
Fault Counter
d080
R
0 to 65535
1 [time]
0012 hex
0011 hex
Fault Monitor 1 Fault
Factor
d081
R
Refer to Inverter trip
fault factor list on
page 8-46.
−
0013 hex
0012 hex
Fault Monitor 1 Inverter
Status
Refer to Inverter trip
fault factor list on
page 8-46.
−
0014 hex
0013 hex
Fault Monitor 1 Frequency
(HIGH)
0 to 59000
0.01
[Hz]
0015 hex
0014 hex
Fault Monitor 1 Frequency
(LOW)
0016 hex
0015 hex
Fault Monitor 1 Output
Current
Output current
value at the time of
trip
0.01 [A]
0017 hex
0016 hex
Fault Monitor 1 Main circuit
DC voltage
DC input voltage at
the time of trip
0.1 [V]
0018 hex
0017 hex
Fault Monitor 1 Total RUN
Time (HIGH)
Total RUN time
before the trip
1 [h]
0019 hex
0018 hex
Fault Monitor 1 Total RUN
Time (LOW)
001A hex
0019 hex
Fault Monitor 1 Total
Power ON Time (HIGH)
Total power ON
time before the trip
1 [h]
001B hex
001A hex
Fault Monitor 1 Total
Power ON Time (LOW)
001C hex
001B hex
Fault Monitor 2 Fault
Factor
d082
R
Refer to Inverter trip
fault factor list on
page 8-46.
−
001D hex
001C hex
Fault Monitor 2 Inverter
Status
Refer to Inverter trip
fault factor list on
page 8-46.
−
001E hex
001D hex
Fault Monitor 2 Frequency
(HIGH)
0 to 59000
0.01
[Hz]
001F hex
001E hex
Fault Monitor 2 Frequency
(LOW)
0020 hex
001F hex
Fault Monitor 2 Output
Current
Output current
value at the time of
trip
0.01 [A]
0021 hex
0020 hex
Fault Monitor 2 Main circuit
DC voltage
DC input voltage at
the time of trip
0.1 [V]
0022 hex
0021 hex
Fault Monitor 2 Total RUN
Time (HIGH)
Total RUN time
before the trip
1 [h]
0023 hex
0022 hex
Fault Monitor 2 Total RUN
Time (LOW)
0024 hex
0023 hex
Fault Monitor 2 Total
Power ON Time (HIGH)
Total power ON
time before the trip
1 [h]
0025 hex
0024 hex
Fault Monitor 2 Total
Power ON Time (LOW)
*1. Data can be written to the PID feed back register when the PID Feedback Selection (A076) is set to 02 (Mod-
bus communication).

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
