8 Communications Functions
8 - 75
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Register
No.
Modbus
register
spec. No
Function name
Parameter
No.
R/W
Monitor or setting data
Data
resolution
Page
141B hex
141A hex
EO Selection
C027
R/W
00: Output frequency
01: Output current
02:
Output torque
*1
03: Digital output fre-
quency
04: Output voltage
05: Input power
06: Electronic thermal
load rate
07: LAD frequency
08: Digital current
monitor
10: Cooling fin tem-
perature
12: DriveProgramming
(YA(0))
15: Pulse train input
monitor
16: Option (No applica-
ble Option)
−
P. 7-27
141C hex
141B hex
AM Selection
C028
R/W
00: Output frequency
01: Output current
02:
Output torque
*1
04: Output voltage
05: Input power
06: Electronic thermal
load rate
07: LAD frequency
10: Cooling fin tem-
perature
11: Output torque
(signed)
*1
13: DriveProgramming
(YA(1))
16: Option (No applica-
ble Option)
−
P. 7-29
141D hex
−
Reserved
−
−
−
−
−
141E hex
141D hex
Digital Current
Monitor Reference
Value
C030
R/W
200 to 2000
0.1 [%]
P. 7-27
141F hex
141E hex
Multi-function Output
11 Operation
Selection
C031
R/W
00: NO (NO contact)
01: NC (NC contact)
−
P. 5-54
1420 hex
141F hex
Multi-function Output
12 Operation
Selection
C032
R/W
00: NO (NO contact)
01: NC (NC contact)
−
1421 to
1423 hex
−
Reserved
−
−
−
−
−
*1. This setting is enabled only when the 1st/2nd Control Method (A044/A244) is set to 03 (Sensorless vector con-
trol).
8
8-9 Modbus Communication Data Lists
8-9-4 Group A/b/C/H/P Register List
