Register
No.
Modbus
register
spec. No
Function name
Parameter
No.
R/W
Monitor or setting data
Data
resolution
Page
1424 hex
1423 hex
Multi-function Relay
Output (AL1, AL2)
Operation Selection
C036
R/W
00: NO (NO contact)
01: NC (NC contact)
−
P. 5-54
1425 hex
−
Reserved
−
−
−
−
−
1426 hex
1425 hex
Low Current Signal
Output Selection
C038
R/W
00: During accelera-
tion/deceleration
and constant
speed
01: Only during con-
stant speed
−
P. 7-89
1427 hex
1426 hex
Low Current Detec-
tion Level
C039
R/W
0 to 2000
0.1 [%]
1428 hex
1427 hex
Overload Warning
Signal Output
Selection
C040
R/W
00: Enabled during
acceleration/decel-
eration and con-
stant speed
01: Enabled during
constant speed
−
P. 7-78
1429 hex
1428 hex
1st Overload
Warning Level
C041
R/W
0 to 2000
0.1 [%]
142A hex
1429 hex
Arrival Frequency
During Acceleration
1
C042
(HIGH)
R/W
0 to 59000
0.01
[Hz]
P. 7-83
142B hex
142A hex
C042
(LOW)
R/W
142C hex
142B hex
Arrival Frequency
During Deceleration
1
C043
(HIGH)
R/W
0 to 59000
0.01
[Hz]
142D hex
142C hex
C043
(LOW)
R/W
142E hex
142D hex
PID Deviation
Excessive Level
C044
R/W
0 to 1000
0.1 [%]
P. 7-44
142F hex
142E hex
Arrival Frequency
During Acceleration
2
C045
(HIGH)
R/W
0 to 59000
0.01
[Hz]
P. 7-83
1430 hex
142F hex
C045
(LOW)
R/W
1431 hex
1430 hex
Arrival Frequency
During Deceleration
2
C046
(HIGH)
R/W
0 to 59000
0.01
[Hz]
1432 hex
1431 hex
C046
(LOW)
R/W
1433 hex
1432 hex
Pulse Train Output
EO Scale
C047
R/W
1 to 9999
0.01
P. 7-27
1434 to
1437 hex
−
Reserved
−
−
−
−
−
1438 hex
1437 hex
Feedback
Comparison Signal
Off Level
C052
R/W
0 to 1000
0.1 [%]
P. 7-44
1439 hex
1438 hex
Feedback
Comparison Signal
On Level
C053
R/W
0 to 1000
0.1 [%]
