Omron MX2 Series User Manual

8 Communications Functions
8 - 86
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Register
No.
Modbus
register
spec. No
Function name
Parameter
No.
R/W
Monitor or setting data
Data
resolution
Page
1639 hex
1638 hex
Pulse Train
Frequency Scale
P055
R/W
10 to 320 * Input fre-
quency at maximum fre-
quency
0.1
[kHz]
P. 7-52
163A hex
1639 hex
Pulse Train
Frequency Filter
Time Parameter
P056
R/W
1 to 200
0.01 [s]
163B hex
163A hex
Pulse Train
Frequency Bias
Amount
P057
R/W
−100 to 100
1 [%]
163C hex
163B hex
Pulse Train
Frequency
UpperLimit
P058
R/W
0 to 100
1 [%]
163D hex
163C hex
Pulse Train
Frequency Lower
Limit
P059
R/W
1 to 2000
0.01
[%]
163E hex
163D hex
Multi-step Position
Command 0
P060
(HIGH)
R/W
Position range setting
(reverse side) to posi-
tion range setting (for-
ward side)
1
[pulse]
P. 6-45
163F hex
163E hex
P060
(LOW)
R/W
1640 hex
163F hex
Multi-step Position
Command 1
P061
(HIGH)
R/W
Position range setting
(reverse side) to posi-
tion range setting (for-
ward side)
1
[pulse]
1641 hex
1640 hex
P061
(LOW)
R/W
1642 hex
1641 hex
Multi-step Position
Command 2
P062
(HIGH)
R/W
Position range setting
(reverse side) to posi-
tion range setting (for-
ward side)
1
[pulse]
1643 hex
1642 hex
P062
(LOW)
R/W
1644 hex
1643 hex
Multi-step Position
Command 3
P063
(HIGH)
R/W
Position range setting
(reverse side) to posi-
tion range setting (for-
ward side)
1
[pulse]
1645 hex
1644 hex
P063
(LOW)
R/W
1646 hex
1645 hex
Multi-step Position
Command 4
P064
(HIGH)
R/W
Position range setting
(reverse side) to posi-
tion range setting (for-
ward side)
1
[pulse]
P. 6-45
1647 hex
1646 hex
P064
(LOW)
R/W
1648 hex
1647 hex
Multi-step Position
Command 5
P065
(HIGH)
R/W
Position range setting
(reverse side) to posi-
tion range setting (for-
ward side)
1
[pulse]
1649 hex
1648 hex
P065
(LOW)
R/W
164A hex
1649 hex
Multi-step Position
Command 6
P066
(HIGH)
R/W
Position range setting
(reverse side) to posi-
tion range setting (for-
ward side)
1
[pulse]
164B hex
164A hex
P066
(LOW)
R/W
164C hex
164B hex
Multi-step Position
Command 7
P067
(HIGH)
R/W
Position range setting
(reverse side) to posi-
tion range setting (for-
ward side)
1
[pulse]
164D hex
164C hex
P067
(LOW)
R/W

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
