2 Design
2 - 21
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
3G3MX2-A2110-EV2
3G3MX2-A4110-EV2
to A4150-EV2
Power supply
input terminals terminals
Charge indicator
3G3MX2-A2150-EV2
Power supply
input terminals terminals
Charge indicator
Terminal arrangement
Applicable model
R/L1
S/L2
T/L3
U/T1
V/T2
W/T3
+1
P/+
N/-
RB
G
G
R/L1
S/L2
T/L3
U/T1
V/T2
W/T3
+1
P/+
N/-
RB
G
G
2
2-3 Wiring
2-3-4 Wiring for Main Circuit Terminals
