95
Example
The following program can be entered using the key inputs shown below
. Dis
-
plays will appear as indicated.
00000
00200
00200
L
D
00002
00201READ
NOP
(00)
00201
T
I
M
0
0
0
00201
TIM
DATA
#0000
00201
TIM
#0123
00202READ
NOP
(00)
00202
FUN
(??)
00202
TIMH
(15)
0
0
1
00202
TIMH
DATA
#0000
00202
TIMH
#0500
00203READ
NOP
(00)
Address
Instruction
Operands
00200
LD
00002
00201
TIM
000
#
0123
00202
TIMH(15)
001
#
0500
Inputting, Modifying, and Checking the Program
Section 4-7
