The
status of bit 15 of C+1 determines whether the instruction is for a SYSMAC
NET Link System or a SYSMAC LINK System.
Control Data
SYSMAC NET Link Systems The
destination port number is always set to 0. Set the destination node number
to
0 to send the data to all nodes. Set the
network number to 0 to send data to a
node on the same Subsystem (i.e., network). Refer to the SYSMAC NET Link
System Manual for details.
Word Bits 00 to 07 Bits 08 to 15
C Number
of words (0 to 1000 in 4-digit hexadecimal, i.e., 0000
hex
to 03E8
hex
)
C+1 Network
number (0 to 127 in 2-digit
hexadecimal,
i.e., 00
hex
to 7F
hex
)
Bit 14 ON: Operating level 0
OFF: Operating level 1
Bits 08 to 13 and 15: Set to 0.
C+2 Destination
node (0 to 126 in
2-digit
hexadecimal,
i.e., 00
hex
to 7E
hex
)*
Destination port
NSB: 00
NSU: 01/02
*The node number of the PC executing the send may be set.
SYSMAC LINK Systems Set
the
destination node number to 0 to send the data to all nodes. Refer to the
SYSMAC LINK System Manual for details.
Word Bits 00 to 07 Bits 08 to 15
C Number
of words (0 to 256 in 4-digit hexadecimal, i.e., 0000
hex
to 0100
hex
)
C+1 Response
time limit (0.1 and 25.4
seconds in 2-digit hexadecimal
without decimal point, i.e., 00
hex
to
FF
hex
)
Note: The response time will be
2 seconds if the limit is set to 0
hex
.
There will be no time limit if the
time limit is set to FF
hex
.
Bits 08 to 11:
No. of retries (0 to 15 in
hexadecimal,
i.e., 0
hex
to F
hex
)
Bit 12: Set to 0.
Bit 13 ON: Response not returned.
OFF: Response returned.
Bit 14 ON: Operating level 0
OFF: Operating level 1
Bit 15: Set to 1.
C+2 Destination node (0 to 62 in 2-digit
hexadecimal, i.e., 00
hex
to 3E
hex
)*
Set to 0.
*The node number of the PC executing the send cannot be set.
Examples This
example is for a SYSMAC NET Link System. When 00000 is ON, the follow
-
ing
program transfers the content of IR 001 through IR 005 to LR 20 through LR
24 on node 10.
0005
0000
000A
IR
001
IR 002
IR 003
IR 004
IR 005
LR 20
LR 21
LR 22
LR 23
LR 24
DM 0010
DM 001
1
DM 0012
15 0
SEND(90)
001
LR 20
DM 0010
00000
Node
10
Address Instruction Operands
00000 LD 00000
00001 SEND(90)
001
LR 20
DM 0010
Network Instructions Section 5-26
