5-25-13 DATA SEARCH – SRCH(––)
R
1
: First word in range
IR, SR, AR, DM, HR, TC, LR
N: Number of words
IR, SR, AR, DM, HR, TC, LR, #
Ladder Symbols Operand Data Areas
@SRCH(––)
N
R
1
C
C: Comparison data, result word
IR, SR, AR, DM, HR, LR
SRCH(––)
N
R
1
C
Limitations N must be BCD between 0001 to 6656.
R
1
and R
1
+N–1 must be in the same data area.
Description When
the execution condition is OFF , SRCH(––) is not executed. When the exe -
cution condition is ON, SRCH(––) searches the range of memory from R
1
to
R
1
+N–1 for addresses that contain the comparison data in C. If one or more ad -
dresses
contain the comparison data, the EQ Flag (SR 25506) is turned ON and
the lowest address containing the comparison data is identified in C+1. The ad -
dress is identified differently for the DM area:
1, 2, 3... 1. For
an address in the DM area, the word address is written to C+1. For ex -
ample, if the lowest address containing the comparison data is DM 0114,
then #0114 is written in C+1.
2. For
an address in another data area, the number of addresses from the be -
ginning
of the search is written to C+1. For example, if the lowest address
containing the comparison data is IR 114 and the first word in the search
range is IR 014, then #0100 is written in C+1.
If
none of addresses in the range contain the comparison data, the EQ Flag (SR
25506) is turned OFF and C+1 is left unchanged.
Flags ER: Indirectly
addressed DM word is non-existent. (Content of : DM word is
not BCD, or the DM area boundary has been exceeded.)
N is not BCD between 0001 and 6655.
EQ: ON
when the comparison data has been matched in the search range.
