I/O Refreshing Time The
I/O refreshing time has been reduced for all units, as shown
in the following
table.
I/O Unit Time Required for Refreshing
Standard I/O Units !@3 of the C200H I/O refreshing time
Group-2 High-density I/O Units !@3 of the C200H I/O refreshing time
Special I/O Units $@5 of the C200H I/O refreshing time
1-8-3 Larger Instruction Set
Advanced programming is facilitated by the 225 application instructions avail-
able with the C200HS-CPU01-E, C200HS-CPU03-E, C200HS-CPU21-E, and
C200HS-CPU23-E, or the 229 application instructions available with the
C200HS-CPU31-E
and C200HS-CPU33-E. In addition, programming has been
simplified by the addition of convenient instructions and macro functions. The
new
instructions and functions are covered in detail in
Section
5 Instruction Set
.
Improved Instructions Additional
functions have been
added to the 7 instructions in the following table.
Instruction Additional Function(s)
DIST(80) Stack operation. The stack can contain up to 999 words.
COLL(81) FIFO/LIFO stack operation. The stack can contain up to 999 words.
MLPX(76) 4-to-256 decoder capability.
DMPX(77) 256-to-8 encoder capability.
ADB(50) Signed binary data can be added.
SBB(51) Signed binary data can be subtracted.
INT(89) Can be used to set scheduled interrupts in 1 ms units and control
input interrupts.
Expansion Instructions A
group of 47 instructions have been designated as expansion instructions. An
expansion
instruction does not have a fixed function code; one of the 18 expan
-
sion
instruction function codes must be assigned to it before it can be used in a
program. An instructions tables, which allocates functions codes to expansion
instructions, must be transferred to the C200HS before the expansion instruc-
tions can be used.
New Instructions A
total of 36 new instructions have been added to the C200HS. These instruc
-
tions are listed below. (Instructions with (--) for function codes are expansion
instructions,
which do not have fixed function codes. Some expansion instruc
-
tion
do
have default function codes. The SET and RESET instructions are basic
instructions,
MACRO and TRACE MEMOR
Y SAMPLE instructions are
applied
instructions,
and the other
instructions are expansion applied instructions. A de
-
fault function number is assigned to the TOTALIZING TIMER, TRANSFER
BITS,
AREA RANGE COMP
ARE, MACRO, AND TRACE MEMOR
Y SAMPLE
instructions.
New C200HS Features Section 1-8
