Omron SYSMAC C200HS User Manual

168
Digit Designator The following show examples of the data movements for various values of Di.
0
1
2
3
0
1
2
3
0
1
2
3
0
1
2
3
S
Di:
0031 Di: 0023
Di: 0030Di: 0010
S
S
S
0
1
2
3
D
0
1
2
3
D
0
1
2
3
D
0
1
2
3
D
Flags ER: At least one of the rightmost three digits of Di is not between 0 and 3.
Indirectly
addressed DM word is non-existent. (Content of ∗ DM word is
not BCD, or the DM area boundary has been exceeded.)
5-16-10 TRANSFER BITS – XFRB(62)
C: Control word
IR, SR, AR, DM, TC, HR, LR, #
S: First source word
IR, SR, AR, DM, HR, TC, LR
Ladder Symbols
Operand Data Areas
D: First destination word
IR, SR, AR, DM, HR, LR
XFRB(62)
C
S
D
@XFRB(62)
C
S
D
Limitations The specified source bits must be in the same data area.
The specified destination bits must be in the same data area.
Description When
the execution condition is OFF , XFRB(62) is not executed. When the exe -
cution
condition is ON, XFRB(62) copies the specified source bits to the speci -
fied destination bits. The two rightmost digits of C specify the starting bits in S
and
D and the leftmost two digits indicate the number of bits that will be copied.
First bit of S (0 to F)
First bit of D (0 to F)
Number of bits (01 to FF)
LSBMSB
C
Note 255 (FF) bits or more can not be copied at one time.
Data Movement Section 5-16
