52
AR 0714 (Error History Reset Bit) is turned ON and then OFF by the user to reset
the Error Record Pointer (DM 0969) and thus restart recording error records at
the beginning of the history area.
AR
0715 (Error History Enable Bit) is turned ON by the user to enable error histo -
ry storage and turned OFF to disable error history storage.
Refer to 3-6 DM Area for details on the Error History Area.
Error history bits are refreshed each cycle.
3-5-7 Active Node Flags
AR 08 through AR 1 1 and AR 12 through AR 15 provide flags that indicate which
nodes are active in the SYSMAC LINK System at the current time. These flags
are refreshed every cycle while the SYSMAC LINK System is operating.
The
body of the following table show the node number assigned to each bit. If the
bit is ON, the node is currently active.
Level 0 Level 1 Bit (body of table shows node numbers)
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15
AR 08 AR 12 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
AR 09 AR 13 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
AR 10 AR 14 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
AR 11 AR 15 49 50 51 52 53 54 55 56 57 58 59 60 61 62 * **
*Communication Controller Error Flag
**EEPROM Error Flag
3-5-8 SYSMAC LINK/SYSMAC NET Link System Service Time
AR 16 provides the time allocated to servicing operating level 0 of the SYSMAC
LINK System and/or SYSMAC NET Link System during each cycle when a SYS -
MAC LINK Unit and/or SYSMAC NET Link Unit is mounted to a Rack.
AR
17 provides the time allocated to servicing operating level 1 of the SYSMAC
LINK System and/or SYSMAC NET Link System during each cycle when a SYS -
MAC LINK Unit and/or SYSMAC NET Link Unit is mounted to a Rack.
These
times are recorded in 4-digit BCD to tenths of a millisecond (000.0 ms to
999.9 ms) and are refreshed every cycle.
Bits
15 to 12 11 to 08 07 to 04 03 to 00
10
2
10
1
10
0
10
–1
3-5-9 Calendar/Clock Area and Bits
Calendar/Clock Area A clock is built into the C200HS CPUs. If AR 21 14 (Clock Stop Bit) is OFF , then
the date, day , and time will be available in BCD in AR 18 to AR 20 and AR 2100 to
AR 2108 as shown below . This area can also be controlled with AR 21 13 (30-se -
cond Compensation Bit) and AR 2115 (Clock Set Bit).
Calendar/Clock Bits
Bits Contents Possible values
AR 1800 to AR 1807 Seconds 00 to 59
AR 1808 to AR 1815 Minutes 00 to 59
AR 1900 to AR 1907 Hours 00 to 23 (24-hour system)
AR 1908 to AR 1915 Day of month 01 to 31 (adjusted by month and for leap year)
AR 2000 to AR 2007 Month 1 to 12
AR 2008 to AR 2015 Year 00 to 99 (Rightmost two digits of year)
AR 2100 to AR 2107 Day of week 00 to 06 (00: Sunday; 01: Monday; 02: Tuesday; 03: Wednesday; 04:
Thursday; 05: Friday; 06: Saturday)
AR Area Section 3-5
