Instruction Set Lists Section 5-7
126
Mnemonic PageNameWordsCode
ASL (@) 25 2 ARITHMETIC SHIFT LEFT 154
ASR (@) 26 2 ARITHMETIC SHIFT RIGHT 154
AVG (@) –– 4 AVERAGE VALUE 235
BCD (@) 24 3 BINARY TO BCD 181
BCDL (@) 59 3 DOUBLE BINARY-TO-DOUBLE BCD 182
BCMP (@) 68 4 BLOCK COMPARE 174
BCNT (@) 67 4 BIT COUNTER 283
BIN (@) 23 3 BCD-TO-BINARY 180
BINL (@) 58 3 DOUBLE BCD-TO-DOUBLE BINARY 181
BSET (@) 71 4 BLOCK SET 160
CLC (@) 41 1 CLEAR CARRY 205
CMP 20 3 COMPARE 170
CMPL 60 4 DOUBLE COMPARE 172
CNT None 2 COUNTER 145
CNTR 12 3 REVERSIBLE COUNTER 148
COLL (@) 81 4 DATA COLLECT 164
COLM(@) 64 4 LINE TO COLUMN 201
COM (@) 29 2 COMPLEMENT 249
CPS –– 4 SIGNED BINARY COMPARE 178
CPSL –– 4 DOUBLE SIGNED BINARY COMPARE 179
DBS (@) –– 4 SIGNED BINARY DIVIDE 231
DBSL (@) –– 4 DOUBLE SIGNED BINARY DIVIDE 232
DEC (@) 39 2 BCD DECREMENT 204
DIFD 14 2 DIFFERENTIATE DOWN 131
DIFU 13 2 DIFFERENTIATE UP 131
DIST (@) 80 4 SINGLE WORD DISTRIBUTE 162
DIV (@) 33 4 BCD DIVIDE 212
DIVL (@) 57 4 DOUBLE BCD DIVIDE 213
DMPX (@) 77 4 16-TO-4 ENCODER 188
DSW –– 4 DIGITAL SWITCH 304
DVB (@) 53 4 BINARY DIVIDE 224
END 01 1 END 138
FAL (@) 06 2 FAILURE ALARM AND RESET 275
FALS 07 2 SEVERE FAILURE ALARM 275
FCS (@) –– 4 FCS CALCULATE 283
FDIV (@) 79 4 FLOATING POINT DIVIDE 214
FPD –– 4 FAILURE POINT DETECT 285
HEX (@) –– 4 ASCII-TO-HEXADECIMAL 195
HKY –– 4 HEXADECIMAL KEY INPUT 308
HMS (@) 66 4 SECONDS TO HOURS 184
IL 02 1 INTERLOCK 135
ILC 03 1 INTERLOCK CLEAR 135
INC (@) 38 2 INCREMENT 204
INT (@) 89 4 INTERRUPT CONTROL 262
IORF (@) 97 3 I/O REFRESH 281
JME 05 2 JUMP END 137
JMP 04 2 JUMP 137
KEEP 11 2 KEEP 133
LD None 1 LOAD 129
