Example The following example shows the comparisons made and the results provided
for BCMP(68). Here, the comparison is made during each cycle when 00000 is
ON.
CD 001 Lower limits Upper limits R: HR 05
001 0210 HR 10 0000 HR 11 0100 HR 0500 0
HR 12 0101 HR 13 0200
HR 0501 0
HR 14 0201 HR 15 0300
HR 0502 1
HR 16 0301 HR 17 0400 HR 0503 0
HR 18 0401 HR 19 0500
HR 0504 0
HR 20 0501 HR 21 0600 HR 0505 0
HR 22 0601 HR 23 0700
HR 0506 0
HR 24 0701 HR 25 0800 HR 0507 0
HR 26 0801 HR 27 0900
HR 0508 0
HR 28 0901 HR 29 1000 HR 0509 0
HR 30 1001 HR 31 1100
HR 0510 0
HR 32 1101 HR 33 1200
HR 051 10
HR 34 1201 HR 35 1300 HR 0512 0
HR 36 1301 HR 37 1400
HR 0513 0
HR 38 1401 HR 39 1500
HR 0514 0
HR 40 1501 HR 41 1600
HR 0515 0
BCMP(68)
001
HR 10
HR 05
00000
Compare data in IR 001
(which contains 0210)
with the given ranges.
Address Instruction Operands
00000 LD 00000
00001 BCMP(68)
001
HR 10
HR 05
5-17-5 TABLE COMPARE – TCMP(85)
CD: Compare data
IR, SR, AR, DM, HR, TC, LR, #
TB: First comparison table word
IR, AR, DM, HR, TC, LR
Ladder Symbols
Operand Data Areas
R: Result word
IR, SR, AR, DM, HR, TC, LR
TCMP(85)
CD
TB
R
@TCMP(85)
CD
TB
R
Limitations TB and TB+15 must be in the same data area.
Description When
the execution condition is OFF , TCMP(85) is not executed. When the exe -
cution condition is ON, TCMP(85) compares CD to the content of TB, TB+1,
TB+2, ..., and TB+15. If CD is equal to the content of any of these words, the
corresponding bit in R is set, e.g., if the CD equals the content of TB, bit 00 is
turned
ON, if it equals that of TB+1, bit 01 is turned ON, etc. The rest of the bits in
R will be turned OFF.
Flags ER: The
comparison table (i.e., TB through TB+15) exceeds the data area.
Indirectly addressed DM word is non-existent. (Content of ∗ DM word is
not BCD, or the DM area boundary has been exceeded.)
Data Comparison Section 5-17
