22
3. Remove
the bracket from the Memory Cassette, as shown in the illustration
below.
Metal bracket
4. Check that the connector side goes in first and that the Cassette’s circuit
components
face right and then insert the Cassette into the CPU. The Cas
-
sette slides in along a track in the CPU.
5. Replace the Memory Cassette bracket over the Cassette and tighten the
screw that holds the bracket.
Installing Memory Cassettes Section 2-5
