347
Key Sequence
Cancels
monitor
operation
Clears leftmost
address
Examples
The following examples show various applications of this monitor operation.
Program Read then Monitor
Indicates
Completion flag is ON
Monitor operation
is cancelled
00100
00100READ
T
I
M
0
0
0
T000
1234
T001
o
0000
00100
T
I
M
0
0
1
Monitoring Operation and Modifying Data
Section 7-1
354
