361
7-1-12 Binary Data Modification
This
operation assigns a new 16-digit binary value to an IR, HR, AR, LR, or DM
word.
The
cursor
, which can be shifted to the left with the up key and to the right with the
down
key
, indicates the position of the bit that can be changed. After
positioning
to
the desired bit, a 0 or a 1 can then be entered as the new
bit value. The bit can
also be Force Set or Force Reset by pressing SHIFT and either PLAY/SET or
REC/RESET.
An S or R will then appear at that bit position. Pressing the NOT
key
will clear the force status, S will change to 1, and R to o. After a bit value has
been
changed, the blinking square will appear at the next position to the right
of
the changed bit.
Key Sequence
Word currently
displayed in binary
.
(Force Status Clear)
Monitoring Operation and Modifying Data Section 7-1
