Omron SYSMAC C200HS

Standard Models Appendix A
434
C200H Standard I/O Units
Name Specifications Model number
Input Units AC Input Unit 8 pts 100 to 120 VAC C200H-IA121
16 pts 100 to 120 VAC C200H-IA122/122V
8 pts 200 to 240 VAC C200H-IA221
16 pts 200 to 240 VAC C200H-IA222/222V
DC Input Unit 8 pts No-voltage contact; NPN C200H-ID001
8 pts No-voltage contact; PNP C200H-ID002
8 pts 12 to 24 VDC C200H-ID211
16 pts 24 VDC C200H-ID212
AC/DC Input Unit 8 pts 12 to 24 VAC/DC C200H-IM211
16 pts 24 VAC/DC C200H-IM212
Interrupt Input Unit
1
8 pts 12 to 24 VDC C200HS-INT01
Output Units Relay Output Unit 8 pts 2 A, 250 VAC/24 VDC (For resistive loads) C200H-OC221
12 pts 2 A, 250 VAC/24 VDC (For resistive loads) C200H-OC222
16 pts 2 A, 250 VAC/24 VAC (For resistive loads) C200H-OC225
2, 3
5 pts 2 A, 250 VAC/24 VDC (For resistive loads)
Independent commons
C200H-OC223
8 pts 2 A, 250 VAC/24 VDC (For resistive loads)
Independent commons
C200H-OC224
12 pts 2 A, 250 VAC/24 VDC (For resistive loads) C200H-OC222V
16 pts 2 A, 250 VAC/24 VDC (For resistive loads) C200H-OC226
8 pts 2 A, 250 VAC/24 VDC (For resistive loads)
Independent commons
C200H-OC224V
Triac Output Unit 8 pts 1 A, 120 VAC C200H-OA121-E
8 pts 1.2 A, 120 VAC C200H-OA122-E
8 pts 1 A, 200 VAC C200H-OA221
12 pts 0.3 A, 250 VAC C200H-OA222V
12 pts 0.5 A, 250 VAC C200H-OA224
Transistor Output
Ui
8 pts 1 A, 12 to 48 VDC C200H-OD411
p
Unit
12 pts 0.3 A, 24 VDC C200H-OD211
16 pts 0.3 A, 24 VDC C200H-OD212
2
8 pts 2.1 A, 24 VDC C200H-OD213
8 pts 0.8 A, 24 VDC; source type (PNP); with load
short protection
C200H-OD214
8 pts 5 to 24 VDC; source type (PNP) C200H-OD216
12 pts 5 to 24 VDC; source type (PNP) C200H-OD217
16 pts 1.0 A, 24 VDC; source type (PNP); with load
short protection
C200H-OD21A
Analog Timer Unit 4 timers 0.1 to 1 s/1 to 10 s/10 to 60 s/1 min to 10 min
(switchable)
C200H-TM001
Variable Resistor
Connector
Connector w/lead wire (2 m) for 1 external resistor C4K-CN223
Standard B7A Interface Units
16 input pts
Connects to B7A Link Terminals.
C200H-B7AI1
16 output pts C200H-B7AO1
Note 1. If the Interrupt Input Unit is mounted on an Expansion I/O Rack, the interrupt function cannot be used and the Inter -
rupt
Input Unit will be treated as an ordinary 8-point Input Unit. Moreover , Interrupt Input Units cannot be used on
Slave Racks. In addition, Interrupt Input Units require that a version 2 (i.e., model numbers with a “-V2” suf fix) Back -
plane
be used at the CPU Rack. If an earlier version Backplane is mounted, the interrupt function cannot be used.
2. Transistor Output Unit C200H-OD212 and Contact Output Unit C200H-OC225 must be mounted to either a C200H-
BC031-V1/V2, C200H-BC051-V1/V2, C200H-BC081-V1/V2, or C200H-BC101-V1/V2 Backplane.
3. The C200H-OC225 might overheat if more than 8 outputs are turned ON simultaneously.
