Appendix AStandard Models
437
SYSMAC LINK Unit/SYSMAC NET Link Unit
The
SYSMAC LINK Units and SYSMAC NET
Link Unit can only be used with the C200HS-CPU31-E and C200HS-
CPU33-E
CPUs.
Name Specifications Model number
SYSMAC LINK Unit Wired via coaxial cable.
Bus Connection Unit required separately. One
C1000H-CE001 F Adapter included.
C200HS-SLK22
Wired via optical fiber cable.
Bus Connection Unit required separately. An Optical Fiber
Cable Bracket must be used to support an optical cable con-
nected to the SYSMAC LINK Unit.
C200HS-SLK12
Terminator One required for each node at ends of System C1000H-TER01
Attachment Stirrup Provided with SYSMAC LINK Unit C200H-TL001
F Adapter --- C1000H-CE001
F Adapter Cover --- C1000H-COV01
Communications
Coaxial cables Manufactured by Hitachi ECXF5C-2V
Cable
Manufactured by Fujigura 5C-2V
Auxiliary Power Sup-
ply Unit
Supplies backup power to either one or two SYSMAC LINK
Units. One C200H-CN111 Power Connecting Cable included.
C200H-APS03
SYSMAC NET Link Unit Bus Connection Unit required separately. An Optical Fiber
Cable Bracket must be used to support an optical cable con-
nected to the SYSMAC NET Link Unit.
C200HS-SNT32
Power Supply Adapt- Required when supplying power from Central
Power Supply
For 2 Units C200H-APS02
Power Cable
Connects Power Supply Adapter and SYS-
MAC NET Link Unit
For 2 Units C200H-CN211
Bus Connection Unit
Connects SYSMAC LINK Unit or SYSMAC
NET Li k U i C200HS CPU31 E/CPU33 E
For 1 Unit C200H-CE001
NET Link Unit to C200HS-CPU31-E/CPU33-E
For 2 Units C200H-CE002
Optional Products
Name Specifications Model number
I/O Unit Cover Cover for 10-pin terminal block C200H-COV11
Terminal Block Cover Short protection for 10-pin terminal block C200H-COV02
Short protection for 19-pin terminal block C200H-COV03
Connector Cover Protective cover for unused I/O Connecting Cable connectors C500-COV02
Space Unit Used for vacant slots C200H-SP001
Battery Set For C200H RAM Memory Unit only C200H-BAT09
Relay 24 VDC G6B-1174P-FD-US
DC24
Backplane Insulation Plate For 10-slot Backplane C200H-ATTA1
For 8-slot Backplane C200H-ATT81
For 5-slot Backplane C200H-ATT51
For 3-slot Backplane C200H-ATT31
I/O Bracket For 10-slot Backplane C200H-ATTA3
For 8-slot Backplane C200H-ATT83
For 5-slot Backplane C200H-ATT53
For 3-slot Backplane C200H-ATT33
Note 1. When ordering, specify the model name (any component of which is not sold separately).
2. Order the press-fit tool from the manufacturer.
