Appendix AStandard Models
439
Name Model numberSpecifications
All Plastic Optical Fiber Cable Set 1-m cable with an Optical Connector A connected to each
end
3G5A2-PF101
Optical Fiber Processing Kit Accessory: 125-mm nipper (Muromoto Tekko’s 550M) for
APF
3G2A9-TL101
H-PCF
Name Specifications Model number
Optical Fiber Cable
10 m, black Two-core cable S3200-HCCB101
SYSMAC BUS, SYSMAC WAY
50 m, black
S3200-HCCB501
100 m, black S3200-HCCB102
500 m, black S3200-HCCB502
1000 m, black S3200-HCCB103
10 m, orange S3200-HCCO101
50 m, orange S3200-HCCO501
100 m, orange
S3200-HCCO102
500 m, orange
S3200-HCCO502
1000 m, orange
S3200-HCCO103
10 m, black Two-core cable S3200-HBCB101
50 m, black S3200-HBCB501
100 m, black S3200-HBCB102
500 m, black S3200-HBCB502
1000 m, black S3200-HBCB103
Optical Fiber Cable Connector SYSMAC BUS:
C200H-RM001-PV1
C200H-RT001/RT002-P
C500-RM001-(P)V1
C500-RT001/RT002-(P)V1
B500-jjj(-P)
Half-lock connector
for Remote I/O Mas-
ter, Remote I/O
Slave, Host Link
Unit, and Link
Adapter
S3200-COCH82
Note 1. Optical fiber cables must be prepared and connected by specialists.
2. If
the user prepares and connects optical fiber
cables, the user must take a seminar held under the aus
-
pices of Sumitomo Electric Industries, Ltd. and obtain a proper certificate.
3. The
Optical Power T
ester
, Head Unit, Master Fiber Set, and Optical Fiber Assembling T
ool are required
to connect optical fiber cables.
Optical Fiber Assembling Tool
Name Specifications Model number
Optical Fiber Assembling Tool Used to connect H-PCF and crimp-cut connectors for opti-
cal transmission systems such as the SYSMAC C- and
CV-series SYSMAC BUS, SYSMAC LINK and SYSMAC
NET.
S3200-CAK1062
Note 1. Optical fiber cables must be prepared and connected by specialists.
2. The
Optical Power T
ester
, Head Unit, Master Fiber set, and Optical Fiber Assembling T
ool are required
to connect optical fiber cables.
To Next Page
