Omron SYSMAC C200HS User Manual

Appendix AStandard Models
441
An Optical Fiber Cable Bracket must be used to support an optical fiber cable connected to the C200HS-SNT32
SYSMAC NET Link Unit or C200HS-SLK12 SYSMAC LINK Unit.
User optical fiber cables with both tension members and power supply lines.
The
following half-lock connector is used and connects to the C200HS SYSMAC LINK and SYSMAC NET Link
Units: S3200-COCF2511.
The
following full-lock connector is used and connects to the CV500 SYSMAC LINK and SYSMAC NET Link Units
and the C1000H SYSMAC LINK Unit: S3200-COCF2011. This full-lock connector cannot be connected to the
C200HS
SYSMAC LINK and SYSMAC NET Link Units.
The above connectors cannot be used for the C500 SYSMAC NET Link Unit, cable relays, and the SYSMAC NET
Link Network Service Board. Refer to the SYSMAC NET Link System Manual for further information.
Programming Devices
Name Specifications Model number
Programming Console Hand-held, w/backlight; requires the C200H-CN222 or
C200H-CN422, see below
C200H-PR027-E
2-m Connecting Cable attached. CQM1-PRO01-E
Programming Console
Mounting Bracket
Used to attach Hand-held Programming Console to a panel. C200H-ATT01
Programming Console Con-
ti C bl
For Hand-held Programming Console 2 m C200H-CN222
gg
necting Cables
4 m C200H-CN422
Data Setting Console Used for data input and process value display for the
C200H-TCjjj, C200H-TVjjj, C200H-CP1
14, and
C200H-PID0j.
C200H-DSC01
Data Setting Console
Connecting Cables
For C200H-DSC01 2 m C200H-CN225
Connecting
Cables
4 m C200H-CN425
Connecting Cable Used to connect an IBM PC/AT or com-
patible to the C200HS.
3.3 m CQM1-CIF02
Ladder Support Software (LSS)
Name Specifications Model number
Ladder Support Software (for
C20, CjjP, CjjK, C120,
C CCSC
5.25”, 2D for IBM PC/AT compatible C500-SF711-EV3
C0,Cjj ,Cjj ,C 0,
CjjH, C200H, C200HS, C500,
C1000H, C2000H, and CQM1)
3.5”, 2HD for IBM PC/AT compatible C500-SF312-EV3
SYSMAC Support Software (SSS)
Product Description Model no.
SYSMAC Support Software
3.5”, 2HD for IBM PC/AT compatible C500-ZL3AT1-E
Training Materials
Name Specifications Model number
SYSMAC Training System Includes text book, cassette tape, and input switch
board.
C200H-ETL01-E
Fuzzy Training System Includes a Fuzzy Training System Manual, a Main Unit,
a C200H-MR831 Memory Unit, a C200H-PRO27-E
Programming Console, a C200H-CN222 Cable for the
Programming Console, C500-SU381-E Fuzzy Training
Software, an RS-232C Cable, and a carrying belt.
C200H-ETL13-E
