Omron SYSMAC C200HS User Manual

Appendix DMemory Areas
458
AR Area
Word(s) Bit(s) Function
00 00 to 09 Error Flags for Special I/O Units 0 to 9 (also function as Error Flags for PC Link Units)
10 Error Flag for operating level 1 of SYSMAC LINK or SYSMAC NET Link System
11 Error Flag for operating level 0 of SYSMAC LINK or SYSMAC NET Link System
12 Host Computer to Rack-mounting Host Link Unit Level 1 Error Flag
13 Host Computer to Rack-mounting Host Link Unit Level 0 Error Flag
14 Remote I/O Master Unit 1 Error Flag
15 Remote I/O Master Unit 0 Error Flag
01 00 to 09 Restart Bits for Special I/O Units 0 to 9 (also function as Restart Bits for PC Link Units)
10 Restart Bit for operating level 1 of SYSMAC LINK or SYSMAC NET Link System
11 Restart Bit for operating level 0 of SYSMAC LINK or SYSMAC NET Link System
12, 13 Not used.
14 Remote I/O Master Unit 1 Restart Flag.
15 Remote I/O Master Unit 0 Restart Flag.
02 00 to 04 Slave Rack Error Flags (#0 to #4)
05 to 14 Group-2 High-density I/O Unit Error Flags
15 Group-2 High-density I/O Unit Error Flag
03 00 to 15 Error Flags for Optical I/O Units 0 to 7
04 00 to 15 Error Flags for Optical I/O Units 8 to 15
05 00 to 15 Error Flags for Optical I/O Units 16 to 23
06 00 to 15 Error Flags for Optical I/O Units 24 to 31
07 00 to 03 Data Link setting for operating level 0 of SYSMAC LINK System
04 to 07 Data Link setting for operating level 1 of SYSMAC LINK System
08 Normal TERMINAL Mode/Expansion TERMINAL Mode Input Cancel Bit
09 Expansion TERMINAL Mode Changeover Flag
10 and 1 1 Reserved by system.
12 T erminal Mode Flag
ON: Expansion; OFF: Normal (Same as status of pin 6 on CPU’s DIP switch)
13 Error History Overwrite Bit
14 Error History Reset Bit
15 Error History Enable Bit
08 to 1 1 00 to 15 Active Node Flags for SYSMAC LINK System nodes of operating level 0
12 to 15 00 to 15 Active Node Flags for SYSMAC LINK System nodes of operating level 1
16 00 to 15 SYSMAC LINK/SYSMAC NET Link System operating level 0 service time per cycle
17 00 to 15 SYSMAC LINK/SYSMAC NET Link System operating level 1 service time per cycle
18
00 to 07 Seconds: 00 to 99
Writeable
08 to 15 Minutes: 00 to 59
19
00 to 07 Hours: 00 to 23 (24-hour system)
Writeable
08 to 15 Day of Month: 01 to 31 (adjusted by month and for leap year)
20
00 to 07 Month: 1 to 12
Writeable
08 to 15 Year: 00 to 99 (Rightmost two digits of year)
21
Wri
teab
l
e
00 to 07 Day of Week: 00 to 06 (00: Sunday; 01: Monday; 02: Tuesday; 03: Wednesday; 04:
Thursday; 05: Friday; 06: Saturday)
Writeable
08 to 12 Not used.
13 30-second Compensation Bit
14 Clock Stop Bit
15 Clock Set Bit
22 00 to 15 Keyboard Mapping
