Host Link Systems
Both
Error flags and Restart bits are
provided for Host Link Systems. Error flags
turn
ON to indicate errors in Host Link Units. Restart bits are turned ON and then
OFF
to restart a Host Link Unit. SR bits used with Host Link Systems are summa
-
rized in the following table. Rack-mounting Host Link Unit Restart bits are
not
effective for the Multilevel Rack-mounting Host Link Units.
Refer to the
Host Link System Manual for details.
Bit Flag
25206 Rack-mounting Host Link Unit Level 1 Error Flag
25207 Rack-mounting Host Link Unit Level 1 Restart Bit
25213 Rack-mounting Host Link Unit Level 0 Restart Bit
25311 Rack-mounting Host Link Unit Level 0 Error Flag
PC Link Systems
When
the PC belongs to a PC Link System, words 247
through 250 are used to
monitor
the operating status of all
PC Link Units connected to the PC Link Sys
-
tem.
This includes a maximum of 32 PC Link Units. If the PC is in a Multilevel PC
Link
System, half of the PC Link Units will be in a PC Link Subsystem in operating
level
0; the other half, in a Subsystem in operating level 1. The actual bit assign
-
ments depend on whether the PC is in
a
Single-level PC Link System or a Multi
-
level
PC Link System. Refer to the
PC Link System Manual
for details. Error and
Run Flag bit assignments are described below.
Bits
00 through 07 of each word are the Run flags, which are ON when the
PC
Link Unit is in RUN mode. Bits 08 through 15
are the Error flags, which are ON
when an error has occurred in the PC Link Unit. The following table shows bit
assignments for Single-level and Multi-level PC Link Systems.
Flag type Bit no. SR 247 SR 248 SR 249 SR 250
Run flags 00 Unit #24 Unit #16 Unit #8 Unit #0
01 Unit #25 Unit #17 Unit #9 Unit #1
02 Unit #26 Unit #18 Unit #10 Unit #2
03 Unit #27 Unit #19 Unit #11 Unit #3
04 Unit #28 Unit #20 Unit #12 Unit #4
05 Unit #29 Unit #21 Unit #13 Unit #5
06 Unit #30 Unit #22 Unit #14 Unit #6
07 Unit #31 Unit #23 Unit #15 Unit #7
Error flags 08 Unit #24 Unit #16 Unit #8 Unit #0
09 Unit #25 Unit #17 Unit #9 Unit #1
10 Unit #26 Unit #18 Unit #10 Unit #2
11 Unit #27 Unit #19 Unit #11 Unit #3
12 Unit #28 Unit #20 Unit #12 Unit #4
13 Unit #29 Unit #21 Unit #13 Unit #5
14 Unit #30 Unit #22 Unit #14 Unit #6
15 Unit #31 Unit #23 Unit #15 Unit #7
PC Link Unit Error and Run
Flags
Single-level PC Link
Systems
SR Area Section 3-4
