Word(s) FunctionBit(s)
01 00
to 09
Restart Bits for Special I/O Units 0 to 9 (also function as Restart Bits for PC Link Units)
10 Restart Bit for operating level 1 of SYSMAC LINK or SYSMAC NET Link System
11 Restart Bit for operating level 0 of SYSMAC LINK or SYSMAC NET Link System
12, 13
Not used.
14 Remote I/O Master Unit 1 Restart Flag.
15 Remote I/O Master Unit 0 Restart Flag.
02
00 to 04
Slave Rack Error Flags (#0 to #4)
05 to 14
Group-2 Error Flags
15 Group-2 Error Flag
03
00 to 15
Error Flags for Optical I/O Units and I/O Terminals 0 to 7
04
00 to 15
Error Flags for Optical I/O Units and I/O Terminals 8 to 15
05
00 to 15
Error Flags for Optical I/O Units and I/O Terminals 16 to 23
06
00 to 15
Error Flags for Optical I/O Units and I/O Terminals 24 to 31
07
00 to 03
Data Link setting for operating level 0 of SYSMAC LINK System
04 to 07
Data Link setting for operating level 1 of SYSMAC LINK System
08 Normal TERMINAL Mode/Expansion TERMINAL Mode Input Cancel Bit
09 Expansion TERMINAL Mode Changeover Flag
10 and 1
1 Reserved by system.
12 T
erminal Mode Flag
ON: Expansion; OFF: Normal (Same as status of pin 6 on CPU’s DIP switch)
13 Error History Overwrite Bit
14 Error History Reset Bit
15 Error History Enable Bit
08 to 1
1
00 to 15
Active Node Flags for SYSMAC LINK System nodes of operating level 0
12 to 15 00 to 15
Active Node Flags for SYSMAC LINK System nodes of operating level 1
16
00 to 15
SYSMAC LINK/SYSMAC NET Link System operating level 0 service time per cycle
17
00 to 15
SYSMAC LINK/SYSMAC NET Link System operating level 1 service time per cycle
18
00 to 07
Seconds: 00 to 99
Writeable
08 to 15
Minutes: 00 to 59
19
00 to 07
Hours: 00 to 23 (24-hour system)
Writeable
08 to 15
Day of Month: 01 to 31 (adjusted by month and for leap year)
20
00 to 07
Month: 1 to 12
Writeable
08 to 15
Year: 00 to 99 (Rightmost two digits of year)
21
Wri
To Next Page
