Oracle Database Appliance X10 User Manual

Callout Indicator/LED: Color State Meaning
3 • 3a. Oracle Dual Port 25 Gb
Ethernet Adapter, Mellanox,
SFP28 ports: green/amber
--or--
• 3b. Oracle Quad Port
10GBase-T Adapter RJ-45
ports: green/yellow
Oracle Dual Port 25 Gb Ethernet
Adapter, Mellanox. Each port has
one bi-colored status LED:
• Off - No link.
• Solid green - Valid link.
• Flashing green - Link with
packet activity.
• Blinking amber (4Hz) -
Problem with the link.
Oracle Quad Port 10GBase-T
Adapter. Each of the four ports
has:
• Top activity indicator:
– Off - No activity.
– Flashing - Packet
activity.
• Bottom link indicator:
– Off - 100 Mb link.
– Green On - 10GbE link.
– Yellow On - 1GbE link.
4 System locate: white This operates in the same way
as on the front panel.
5 NET 0 port: green 10/100/1000 BASE-T Ethernet
interface.
Bottom left activity indicator:
• Off - No link or link down.
• On - Link up.
• Blinking - Packet activity.
Bottom right link indicator:
• Off - 10/100BASE-T link.
• On - 1000Base-T link.
6 NET MGT port: green 10/100/1000 BASE-T Ethernet
management interface.
Top left speed indicator:
• Off - 10/100BASE-T link.
• On - Green for 1000Base-T
link.
Top right activity indicator:
• Off - No link or link down.
• On - Link up.
• Blinking - Packet activity.
7 System service required and OK:
various
These operate in the same way
as on the front panel.
Oracle Database Appliance X10-HA Status Indicators
Learn about Oracle Database Appliance X10-HA status indicators.
Chapter 1
Oracle Database Appliance X10-HA Status Indicators
1-6
