Oracle Database Appliance X10 User Manual

Description Oracle Database
Appliance X10-S
Oracle Database
Appliance X10-L
Oracle Database
Appliance X10-HA (per
node)
Installation order
Optional network
cards:
1. By default, the
server comes with a
public network card
installed in PCIe
slot 5.
2. A second public
network card can
be installed in PCIe
slot 9.
3.
A third public
network card can
be installed in PCIe
slot 8.
Optional network
cards:
1. By default, the
server comes with a
public network card
installed in PCIe
slot 5.
2. A second public
network card must
be installed in PCIe
slot 4.
3.
A third public
network card must
be installed in PCIe
slot 8.
Optional Oracle Flash
Accelerator 680 PCIe
Cards:
1.
The first Oracle
Flash Accelerator
card must be
installed in PCIe
slot 2.
2. A second Oracle
Flash Accelerator
card must be
installed in PCIe
slot 3.
3. A third Oracle Flash
Accelerator card
must be installed in
PCIe slot 9.
4. A fourth Oracle
Flash Accelerator
card must be
installed in PCIe
slot 1.
Optional network
cards:
1. By default, each
server node comes
with a public
network card
installed in PCIe
slot 5.
2. A second public
network card can
be installed in PCIe
slot 4.
3.
A third public
network card can
be installed in PCIe
slot 8.
Installation intructions: Install a Half Height
PCIe Card
Install a Half Height
PCIe Card
Install a Half Height
PCIe Card
Remove a Half Height PCIe Card
Before replacing or installing a PCIe card, refer to the card documentation for specific
installation and cabling instructions.
1. Prepare the server for service.
a. Power off the server.
See Powering Down the Server.
Chapter 4
Servicing PCIe Cards (CRU)
4-18
